4JH110
Engine Specifications
Application: Sailing Engine
Power Output (HP): 110
Power Output (kW): 80.9
Rated Speed: 3200 RPM
Displacement: 2L
Cylinders: 4
Bore x Stroke: 84mm x 90mm
Aspiration: Turbocharged & Intercooled
Dry Weight: 229 kg
Dimensions: 909 mm x 613 mm x 675 mm
Certifications: RCD 2, EPA Tier 3, EPA Tier 3C, BSO II, EMC, SOLAS
Engine Specifications
Application: Sailing Engine
Power Output (HP): 110
Power Output (kW): 80.9
Rated Speed: 3200 RPM
Displacement: 2L
Cylinders: 4
Bore x Stroke: 84mm x 90mm
Aspiration: Turbocharged & Intercooled
Dry Weight: 229 kg
Dimensions: 909 mm x 613 mm x 675 mm
Certifications: RCD 2, EPA Tier 3, EPA Tier 3C, BSO II, EMC, SOLAS
Engine Specifications
Application: Sailing Engine
Power Output (HP): 110
Power Output (kW): 80.9
Rated Speed: 3200 RPM
Displacement: 2L
Cylinders: 4
Bore x Stroke: 84mm x 90mm
Aspiration: Turbocharged & Intercooled
Dry Weight: 229 kg
Dimensions: 909 mm x 613 mm x 675 mm
Certifications: RCD 2, EPA Tier 3, EPA Tier 3C, BSO II, EMC, SOLAS
The Yanmar JH-CR lineup brings you 5x Best in Class features – Clean, Interconnective, Quiet, Powerful & Fuel Efficient – setting the global standard in sailboat and small craft propulsion. With a range of power ratings across one design, the JH-CR engine is the perfect solution to fit across a wide variety of boats sizes and applications. And with a similar footprint to previous models and competition alike, it is the ideal choice for repowers.
Features
Genuine YANMAR-based engine featuring a custom-designed common rail system
Advanced fuel injection technology for sailboats and smaller motorboats and commercial vessels
Sets the global standard in sailboat and small craft propulsion
Wide range of power ratings in one model to fit a variety of applications
Versatile control options with mechanical control as standard and option to upgrade to electronic controls
Setting the Global Standard
Utilizing the long-established TNV industrial YANMAR block as the durable foundation, the 4JH-CR marine series incorporates an advanced custom-built Bosch common rail fuel injection system, This brings the advantages of common rail technology to sailboats and smaller craft, exclusively from YANMAR for this horsepower range.
JH-CR available in 5 output models – 40, 45, 57, 80, 110 mhp
All 4JH-CR models compatible with YANMAR SD60 saildrive (except the 4JH110)
A proven solution for jet and shaft drives
Controlled electronically by YANMAR VC10 Vessel Control System, with up to 3 stations (mechanical controls as standard)
SOLAS option and USCG lifeboat approved
Certified for recreational and light duty commercial applications
Setting the global standard
YANMAR’s 4JH45 & 4JH57 common rail diesel engines offer class leading features that out performs the competition. Compact, powerful, smooth, quiet, efficient and interconnective, the JH-CR Series is perfect for any application whether rib, tender, sailboat or catamaran, new or re-power. With over a 100 years of innovation, unequaled reliability, and the largest marine engine global service network, choosing a YANMAR ensures you will enjoy many safe and carefree years on the water.
Standard Engine Package
Exhaust mixing elbow [L-type]
Alternator 12V – 125A
Seawater pump rear mounted
B25 panel
Flexible mounts
Mechanical throttle sensor
Fuel pre-filter with water separator
Fresh water expansion tank
Belt safety cover
Optional Accessories
High-riser mixing elbow [instead of L-elbow]
Secondary alternator 12V – 125A or 24V – 60A
Seawater pump front mounted
C35 panel
Extension harness [3m, 5m, 10m]
Second station
Sidemount control head
VC10 Vessel Control System
NMEA2000 Engine monitoring system
SOLAS including Certificate [factory fit only]
Extension saildrive leg [75 mm]
Propeller cone nut kit SD60
On-board spare parts kit
Please contact your nearest dealer or Power Equipment Account Manager for a full list of available options, installation requirements and compatible products.
* All information shown is to be used as general information only. Images shown are for illustration purposes only and may not represent the final product. All dimensions, power outputs and technical details are approximate and may vary from time to time depending on a range of factors. Any data shown is subject to change without notice. Some items or accessories may not be available in all areas/regions. Please consult your Authorised Dealer or Power Equipment Account Manager for all technical information.
