6CXBM-GT (M)

$25.00

Engine Specifications

Application: Commercial Engine

Power Output (HP): 400

Power Output (kW): 294

Rated Speed: 2500 RPM

Displacement: 7.413L

Cylinders: 6

Bore x Stroke: 110mm x 130mm

Aspiration: Turbocharged & Intercooled

Dry Weight: 856kg

Dimensions: 1390mm x 901mm x 989mm

Certifications: IMO Tier 2, RVIR Tier Ⅱ

Quantity:
Add To Cart

Engine Specifications

Application: Commercial Engine

Power Output (HP): 400

Power Output (kW): 294

Rated Speed: 2500 RPM

Displacement: 7.413L

Cylinders: 6

Bore x Stroke: 110mm x 130mm

Aspiration: Turbocharged & Intercooled

Dry Weight: 856kg

Dimensions: 1390mm x 901mm x 989mm

Certifications: IMO Tier 2, RVIR Tier Ⅱ

Engine Specifications

Application: Commercial Engine

Power Output (HP): 400

Power Output (kW): 294

Rated Speed: 2500 RPM

Displacement: 7.413L

Cylinders: 6

Bore x Stroke: 110mm x 130mm

Aspiration: Turbocharged & Intercooled

Dry Weight: 856kg

Dimensions: 1390mm x 901mm x 989mm

Certifications: IMO Tier 2, RVIR Tier Ⅱ



The new generation workboat engine encompasses all the traditions and technology that Yanmar are renowned for – performance, high torque, toughness and reliability – combined with modern eco diesel solutions for low emission boating.

Features:

  • High power with excellent fuel economy

  • Low emissions with IMO Tier 2 compliance

  • Easy maintenance access to keep you on the water for longer

  • All new high efficiency intercooler helps deliver power in large amounts, especially under high loads

This 130mm long stroker 7.4L class diesel, with big breathing valves for better airflow, the high performance turbo for compactness, less turbo lag, the all-new high efficiency intercooler for cooler, more compact air charging, and the numerous other performance features deliver power in large amounts over a wide operating range, especially under high load conditions.

Good fuel economy together with lower emissions

The micro-sized multiple holes in the all-new injectors produce an even finer fuel-oil mist and, combined with new perfectly matched combustion chambers and new cylinder head shapes, produce even more power. It is power delivered smoothly, due to optimum combustion conditions being maintained across a far wider operation range. And it leads directly to the bonus of lower exhaust emissions and lower fuel consumption.

Toughness

Designed specifically for marine use, the Yanmar range of commercial marine engines are the go-to solution for long lasting and reliable propulsion systems across a wide range of uses. Whether it’s commercial ferry services, fishing boats or workboats, no matter the conditions and loads, you can rely on Yanmar.

Simplified Maintenance = Low Downtime

Designed with large inspection windows and easily accessible maintenance and servicing points, the CXB maintenance is simplified and costs are much lower. And less time spent servicing is more time out on the water.



* All information shown is to be used as general information only. Images shown are for illustration purposes only and may not represent the final product. All dimensions, power outputs and technical details are approximate and may vary from time to time depending on a range of factors. Any data shown is subject to change without notice. Some items or accessories may not be available in all areas/regions. Please consult your Authorised Dealer or Power Equipment Account Manager for all technical information.
