6090SFM85

$25.00

Engine Specifications

Application: Sailing Engine, Powerboat Engine, Commercial Engine

Power Output (HP): 550

Power Output (kW): 410

Rated Speed: 2100 RPM (M1)

Displacement: 9.0L

Cylinders: 6

Bore x Stroke: 118.4mm x 136mm

Aspiration: Turbocharged

Dry Weight: 1056kg

Dimensions: 1712mm x 1415mm x 974mm

Certifications: EPA Commercial Marine Tier 3, IMO MARPOL Annex VI Tier II

Quantity:
Add To Cart

Engine Specifications

Application: Sailing Engine, Powerboat Engine, Commercial Engine

Power Output (HP): 550

Power Output (kW): 410

Rated Speed: 2100 RPM (M1)

Displacement: 9.0L

Cylinders: 6

Bore x Stroke: 118.4mm x 136mm

Aspiration: Turbocharged

Dry Weight: 1056kg

Dimensions: 1712mm x 1415mm x 974mm

Certifications: EPA Commercial Marine Tier 3, IMO MARPOL Annex VI Tier II

Engine Specifications

Application: Sailing Engine, Powerboat Engine, Commercial Engine

Power Output (HP): 550

Power Output (kW): 410

Rated Speed: 2100 RPM (M1)

Displacement: 9.0L

Cylinders: 6

Bore x Stroke: 118.4mm x 136mm

Aspiration: Turbocharged

Dry Weight: 1056kg

Dimensions: 1712mm x 1415mm x 974mm

Certifications: EPA Commercial Marine Tier 3, IMO MARPOL Annex VI Tier II



Powerful, reliable, John Deere

Experience the powerful reliability of the John Deere 9.0L PowerTech™ engine range. The 6090SFM85 is available in 242kW-410kW configurations (325-550hp). Featuring constant power to 400 RPM below rated speed makes these engines an excellent choice for patrol craft, launches, work boats, fishing boats, trawler yachts and sport fishing boats.

Features:

  • High torque and low rated RPM for excellent control and manoeuvring

  • Excellent airflow through 4-valve cylinder head delivers greater low-speed torque and better transient response time

  • The high pressure common rail (HPCR) fuel system provides high performance, excellent fuel economy and low emissions

  • Cooler turbocharger operation enables higher ratings and efficiencies for applications that require high power or speed

  • Advanced ECU provides fault code diagnostics and customizable engine protections to ensure reliability and uptime

  • High-capacity heat exchanger provides reliable operation in adverse conditions

  • Either-side oil fill/dipstick combinations and remote oil and fuel filter options are available for easier service access

Sydneysider charter vessel cruises Sydney Harbour powered by the John Deere 6068TFM50

Nothing runs like a Deere™

John Deere PowerTech™ engines are as powerful and dependable in the water as they are on land. Our marine engines share the same reputation for performance and reliability that their agricultural and industrial counterparts have enjoyed for decades. They are built for long life, reliable performance, fuel efficiency, quiet operation, ease of access to major parts and simplified integration. Don’t take our word for it, find out why John Deere is the powerful and reliable choice.



* All information shown is to be used as general information only. Images shown are for illustration purposes only and may not represent the final product. All dimensions, power outputs and technical details are approximate and may vary from time to time depending on a range of factors. Any data shown is subject to change without notice. Some items or accessories may not be available in all areas/regions. Please consult your Authorised Dealer or Power Equipment Account Manager for all technical information.
