6068AFM85
Engine Specifications
Application: Sailing Engine, Powerboat Engine, Commercial Engine
Power Output (HP): 330
Power Output (kW): 246
Rated Speed: 2300 RPM (M1)
Displacement: 6.8L
Cylinders: 6
Bore x Stroke: 107mm x 127mm
Aspiration: Turbocharged
Dry Weight: 787kg
Dimensions: 1489mm x 935mm x 1172mm
Certifications: EPA Commercial Marine Tier 3, IMO MARPOL Annex VI, NRMM (97/68/EC)
Engine Specifications
Application: Sailing Engine, Powerboat Engine, Commercial Engine
Power Output (HP): 330
Power Output (kW): 246
Rated Speed: 2300 RPM (M1)
Displacement: 6.8L
Cylinders: 6
Bore x Stroke: 107mm x 127mm
Aspiration: Turbocharged
Dry Weight: 787kg
Dimensions: 1489mm x 935mm x 1172mm
Certifications: EPA Commercial Marine Tier 3, IMO MARPOL Annex VI, NRMM (97/68/EC)
Engine Specifications
Application: Sailing Engine, Powerboat Engine, Commercial Engine
Power Output (HP): 330
Power Output (kW): 246
Rated Speed: 2300 RPM (M1)
Displacement: 6.8L
Cylinders: 6
Bore x Stroke: 107mm x 127mm
Aspiration: Turbocharged
Dry Weight: 787kg
Dimensions: 1489mm x 935mm x 1172mm
Certifications: EPA Commercial Marine Tier 3, IMO MARPOL Annex VI, NRMM (97/68/EC)
Constant, reliable power you can trust
The 6.8L six-cylinder turbocharged 6068AFM85 PowerTech™ engine features constant power to 400 RPM below rated speed, making these engines an excellent choice for launches, work boats, trawler yachts, and patrol craft.
Features:
High torque and low rated RPM for excellent control and manoeuvring
Replaceable wet-type cylinder liners
High pressure common rail (HPCR) system provides high performance, excellent fuel economy and low emissions
Advanced ECU provides fault code diagnostics and customizable engine protections to ensure reliability and uptime
Hassle free maintenance and servicing with access from both sides of the engine
Closed cooling system in keel-cooled engine option eliminates the need for a sea strainer, seawater pump, or anodes. Heat exchanger option offers a lighter, more compact, and simpler engine installation
Nothing runs like a Deere™
John Deere PowerTech™ engines are as powerful and dependable in the water as they are on land. Our marine engines share the same reputation for performance and reliability that their agricultural and industrial counterparts have enjoyed for decades. They are built for long life, reliable performance, fuel efficiency, quiet operation, ease of access to major parts and simplified integration. Don’t take our word for it, find out why John Deere is the powerful and reliable choice.
* All information shown is to be used as general information only. Images shown are for illustration purposes only and may not represent the final product. All dimensions, power outputs and technical details are approximate and may vary from time to time depending on a range of factors. Any data shown is subject to change without notice. Some items or accessories may not be available in all areas/regions. Please consult your Authorised Dealer or Power Equipment Account Manager for all technical information.
